Cadence extends support for Arm’s Total Compute Solutions 2023

2 mins read

Cadence Design Systems is expanding its collaboration with Arm and supporting the roll-out of silicon for mobile devices.

Consequently, customers will benefit from a faster path to tape-out by using Cadence digital and verification tools supporting Arm’s Total Compute Solutions 2023 (TCS23), which includes the Arm Cortex-X4, Arm Cortex-A720 and Cortex-A520 CPUs and Immortalis-G720, Mali-G720 and Mali-G620 GPUs.

Through this collaboration, Cadence will deliver comprehensive RTL-to-GDS digital flow Rapid Adoption Kits (RAKs) for 3nm and 5nm nodes to help customers reach power and performance goals using the new Arm TCS23.

Cadence’s tools have been optimised for the Arm TCS23 include the Cadence Cerebrus Intelligent Chip Explorer, Genus Synthesis Solution, Modus DFT Software Solution, Innovus Implementation System, Quantus Extraction Solution, Tempus Timing Signoff Solution and ECO Option, Voltus IC Power Integrity Solution, Conformal Equivalence Checking and Conformal Low Power.

Cadence Cerebrus provided Arm with AI-driven design capabilities that have resulted in 50% better timing (TNS), a 10% reduction in cell area and a 27% improvement in leakage power on the Cortex-X4 CPU, allowing Arm to achieve power, performance and area (PPA) targets faster.

The digital RAKs provide Arm TCS23 users with several key benefits. For example, the AI-driven Cadence Cerebrus automates and scales digital chip design, providing customers with improved productivity versus a manual, iterative approach.

Cadence’s iSpatial technology provides an integrated implementation flow, offering improved predictability and PPA, which ultimately leads to faster design closure.

The RAKs also incorporate a smart hierarchy flow that enables accelerated turnaround times on large, high-performance CPUs. The Tempus ECO Option, which provides path-based analysis, is integrated into the flow for signoff-accurate, final design closure.

Finally, the RAKs use the GigaOpt activity-aware power optimisation engine, which is incorporated with the Innovus Implementation System and the Genus Synthesis Solution to dramatically reduce dynamic power consumption.

Arm used the Cadence verification flow to validate the Cortex-X4, Cortex-A720 and Cortex-A520 CPU-based and Immortalis-G720, Mali-G720 and Mali-G620 GPU-based mobile reference platforms and let’s Arm TCS23 users improve overall verification throughput and leverage advanced software debug capabilities.

Cadence also validated that its Perspec System Verifier, VIP and System VIP tools all support TCS23-based designs to enable customers to accelerate time to market when assembling TCS23-based SoCs. In addition, the virtual and hybrid platform reference designs include the Arm Fast Models to enable early software development and verification through the Cadence Helium Studio as well as the Cadence Palladium and Protium platforms.

“With the delivery of Arm TCS23, we’re unlocking the creative potential for customers around the world who demand high performance and efficient compute for next-generation mobile experiences,” said Chris Bergey, senior vice president and general manager, Client Line of Business at Arm. “Through our ongoing collaboration with Cadence, we successfully leveraged the Cadence digital and verification flows to get our latest generation of CPUs and GPUs into our customer’s hands faster and accelerate time to market.”
