Imec launches design pathfinding PDK for most advanced semiconductor technologies

2 mins read

imec, the research and innovation hub in nanoelectronics and digital technologies, has announced the launch of its latest open process design kit (PDK), alongside a training program offered through EUROPRACTICE.

The PDK, the announcement of which was made at the IEEE International Solid-State Circuits Conference (ISSCC), will enable virtual digital designs in imec’s N2 technology, including backside power delivery network.

The PDK will be embedded in EDA tool suites, such as from Cadence Design Systems and Synopsys, providing broad access to advanced nodes for design pathfinding, system research and training and will give academia and industry the necessary tools to enable the industry to transition their products into next generations technologies through meaningful design pathfinding.

Foundry PDKs give chip designers access to a library of tested and proven components to deliver functional and reliable designs and are usually available to the ecosystem once the technology reaches a critical level of manufacturability.

However, restricted access and the need for NDAs have created a high threshold for academia and industry to access advanced technology nodes during their development so access to imec’s N2 PDK will help both academia and commercial companies.

“If we want to engage a new generation of chip designers, we must provide them early access to the infrastructure needed to develop their design skills on the most advanced technology nodes,” said Julien Ryckaert, VP Logic Technologies. He added, “The accompanying training courses will get these designers up to speed as quickly as possible and acquaint them with the most recent technology disruptions such as nanosheet devices and wafer backside technology. The design pathfinding PDK will also help companies to transition their designs to future technology nodes and pre-empt scaling bottlenecks for their products.”

The design pathfinding PDK contains the necessary infrastructure for digital design based on a set of digital standard cell libraries and SRAM IP macros. In the future, the design pathfinding PDK platform will extend to more advanced nodes (e.g. A14). The training program will start early Q2, teaching subscribers the specificities of the N2 technology node and offering hands-on training on digital design platforms using the Cadence and the Synopsys EDA software.

“Nurturing an engineering workforce that is equipped with the necessary technology to develop transformational products is critical to the semiconductor industry,” said Brandon Wang, vice president, technical strategy & strategic partnerships at Synopsys. “Imec’s design pathfinding PDK is an excellent example of how industry partnerships can broaden access to advanced process technology for the current and next generation of designers to accelerate their semiconductor innovation. Our collaboration with imec to deliver a certified, AI-driven EDA digital design flow for its N2 PDK enables design teams to prototype and accelerate the transition to next-generation technologies using a virtual PDK-based design environment.”
