ST’s compact, configurable automotive driver adds extra safety pins

STMicroelectronics has unveiled the L9026 8-channel driver that now has six configurable high-side/low-side outputs and two high-side outputs, delivering a flexible solution for space-constrained applications.

New configurable automotive driver adds extra safety pins Credit: adobe.stock.com

With a limp-home mode in case of controller failure and two extra input pins for failsafe operation, the L9026 has been designed to enhance safety and reliability.

It can drive multiple relays, solenoids, LEDs, and resistive loads in equipment such as body electronics, climate controls, and fuel-injection systems, and the L9026 can also handle resistive, capacitive, and inductive loads.

The device has an SPI interface with registers for storing the device configuration as well as internal mapping and PWM behaviour. The limp-home mode, activated according to register settings OR-ed with the external failsafe pins, allows two drivers to remain operational after detection of a fault or supply undervoltage.

With advanced diagnostic and protection features for each channel, the L9026 eases ISO 26262 system-level qualification up to ASIL-B in safety-related applications.

There is protection against open and short circuits, overcurrent, and overtemperature, with real-time diagnostics available at the SPI interface.

Additional features increase flexibility and save the system bill of materials, such as the bulb-inrush mode that automatically protects against excessive power-on current. The L9026 guarantees operation during cranking with battery voltage as low as 3V.

The choice of packages includes HTSSOP and a 5mm x 5mm x 1mm VFQFPN32 that provides a very compact option for in-vehicle use. The L9026 is in production now.
