Researchers at IMDEA Nanociencia have developed a physically unclonable function based on carbon nanotubes with potential applications in security and anti-counterfeiting.

The ubiquity of electronic devices makes it essential to use encryption and anti-counterfeiting tools to protect the privacy and security of users. With the growing expansion of the Internet of Things, protection against attacks that violate the authenticity of products is increasingly necessary.

Traditionally, message protection has been based on different systems: passwords, digital signatures or encryption. This cryptography is based on unknown keys to a possible attacker, but according to the IMDEA Nanociencia researchers, these systems are becoming obsolete as new more invasive attacks appear.

While quantum computing slowly progresses towards the cryptographic paradigm, the so-called physically unclonable functions (PUFs), a device that has unique and non-repeatable physical properties that can be translated into usable bits of information, show great potential for securing devices of the future.

Authentication based on PUFs comprises a chip manufactured by intrinsically random processes that IMDEA says makes cloning almost impossible, even though all the details of the manufacturing process are known. The measurements of the various physical properties of the PUF depend on the properties of the chip at the nanoscale, thus constitute a very powerful anti-fraud and anti-counterfeiting technology, explains the research team. To be implementable at an industrial level, this chip must be low cost, scalable and its properties must be easily measurable by means of an identifiable function.

Researchers at IMDEA have proposed a simple PUF based on carbon nanotubes. The carbon nanotubes are assembled by dielectrophoresis to a series of 16 electrodes forming random junctions. In each pair of electrodes there are one, several or no nanotubes. The measurement of the intensity-voltage curves provides a unique pattern that is inherent to each PUF and is almost impossible to reproduce, according to IMDEA.

This nanotechnology is said to exploit a characteristic of carbon nanotubes that has usually been detrimental: the difficulty of obtaining carbon nanotubes with identical chirality, that is, with identical electronic properties (conductor or semiconductor).

Also, the inherent manufacturing defects such as vacancies or oxygen functionalities mean that two carbon nanotubes with the same chirality do not have the same conductance. These disadvantages have been transformed into the PUF strongest point, adds IMDEA.

These PUFs conceived at IMDEA are also easily measurable physical devices that provide a pattern of intrinsic conductance to each of them that is extraordinarily difficult to duplicate. Given the same PUF two different inputs produce different responses, and given the same input two PUFs produce two different responses. In this way, these PUFs based on carbon nanotubes can be identified by the value of the responses they generate to specific inputs. Any PUF defect is not valid here; it must be measurable and provide a unique signature.

Currently there are several types of PUFs that are based on physical properties such as reflectivity or magnetic anisotropy. However, according to IMDEA, its method is the cheapest (1 step of lithography) and the most easily implantable in an electronic circuit, as well as being potentially scalable to a greater number of electrodes to increase its complexity.

The group believe that their PUFs could be implemented in smartphones, microcontrollers, smart sensors, actuators, and could also be used as a digital signature.
